Invertor 4000w Mppt 100A Easun Wifi
4000W Solar Inverter Pure Sine Wave Solar Inverser Build In 100A Solar Controller With Wifi
Funcționează numai cu baterii 24V!
Puterea continua 3600w.
Invertor 6,2 kw Accept No Battery Work
1. Invertor sinusoidal pur,
Generează energie direct din panourile fotovoltaice pentru a alimenta sarcina, chiar și fără baterie. Eficiența panourilor fotovoltaice către panourile CA este mult mai mare.
2. Tensiune de intrare configurabilă pentru electrocasnice și computere personale prin setările LCD.
3. Curent de încărcare a bateriei configurabil în funcție de aplicații prin setările LCD.
4. Prioritate de încărcare CA/solară configurabilă prin setările LCD.
5. Repornire automată în timp ce curentul alternativ se restabilește.
6. Protecție la suprasarcină/supratemperatură/scurtcircuit.
7. Design inteligent al încărcătorului de baterii pentru performanțe optimizate ale bateriei.
8. Funcție de pornire la rece.
9. Intrare fotovoltaică MPPT de 4000 W, intrare fotovoltaică largă de 60-500 V, baterie cu litiu.
Kitul de praf trebuie achiziționat suplimentar.
- ISolar-SMG-II-4KW-24V-WIFI User Manual
- Lithium battery activation function by PV or Utility;
- Compatible work with lifepo4 battery via Rs485;
- Pure sine wave;
- Power factor 1.0;
- PV input Voltage 60Vdc-500Vdc;
- Built-in MPPT 100A;
- Not Capable to work without battery;
- Detachable dust cover for harsh environment;
- WiFi remote monitoring optional;
- Support multiple output priority:UTL,SOL,SBU, SUB;
- EQ function to optimize battery performance and extend lifecycle.
The **Easun Hybrid Inverter 4000W with MPPT 100A** is a versatile power solution commonly used in off-grid and hybrid solar systems. Here are some key features and details of this inverter:
### Key Specifications:
– **Power Rating:** 4000W (4kW) continuous output.
– **Battery Voltage:** Typically supports 24V or 48V battery systems (specific model-dependent).
– **MPPT Solar Charger:** 100A maximum charge current, supporting efficient solar power harvesting.
– **Input Voltage Range:** Can vary depending on the model, but usually supports a wide PV input range for flexibility in solar panel configurations.
– **Hybrid Functionality:** Can operate in off-grid mode, grid-tied mode, or a hybrid mode combining both, allowing for seamless power switching.
– **AC Output:** Pure sine wave output, suitable for sensitive electronics.
– **LCD Display:** Provides system status, fault codes, and other critical information.
– **Communication Ports:** Typically includes RS232, USB, or RS485 for monitoring and control, often compatible with remote monitoring apps.
### Common Uses:
– **Residential Solar Power Systems:** Ideal for homes looking to reduce reliance on the grid or go completely off-grid.
– **Backup Power:** Works well as an emergency power backup solution, thanks to its ability to seamlessly switch between grid and battery power.
– **Small Commercial Installations:** Suitable for small businesses or remote offices that need reliable power.
### Advantages:
– **High Efficiency:** The MPPT (Maximum Power Point Tracking) feature ensures that the solar panels operate at their maximum efficiency, significantly improving power output.
– **Hybrid Flexibility:** The ability to work with both grid and solar power provides a more resilient energy solution, making it easier to manage power availability.
– **Scalability:** Often stackable or configurable in parallel to increase system capacity.
### Considerations:
– **System Design:** Ensure compatibility with your battery bank (voltage and capacity) and solar panel array (voltage and current).
– **Installation:** Proper installation is crucial, often requiring a qualified technician to ensure safety and optimal performance.
This inverter is popular among DIY solar enthusiasts and those looking for a reliable, cost-effective way to manage their energy needs in a hybrid solar setup.
Garanția 1 an pentru invertorul 4000w Mppt 100A Easun in România.
